STEEL FRAMING STUDS AND TRACK
When choosing a supplier, quality materials are a top priority. That's why SCAFCO steel framing products are manufactured from 100% prime mill certified steel. SCAFCO's products exceed industry standards as they are manufactured from 57 ksi steel in place of 50 ksi and G90 in place of G60 for 68 mil and heavier.
Applications
Non-load-bearing exterior curtain walls
Axial load-bearing interior and exterior walls
Interior non-load-bearing walls
Floor joists and headers
Rafters, purlins, and girts
AISI and ASTM Code Standards
AISI's North American Specification for the Design of Cold-Formed Steel Structural Members
A653-- Standard specification for steel sheet, zinc-coated (galvanized) by the hot-dip process
A1003-- Standard specification for steel sheet, carbon, and metallic-coated for cold-formed framing members
C645-- Standard specification for nonstructural steel framing members
C754-- Standard specification for installation of steel framing members to receive screw-attached gypsum panel products
C955-- Standard specification for load-bearing (transverse and axial) steel studs, runners (tracks), and bracing or bridging for screw application of gypsum panel products and metal plaster bases
E72-- Standard test methods of conducting strength tests of panels for building construction
E90-- Standard test method for laboratory measurement of airborne sound transmission loss of building partitions and elements
E119-- Standard test methods for fire tests of building construction and materials
Steel frame stud and track table
| Series | Name | Part Name | Specification(mm) | |
| A*B | Thickness | |||
| Ceiling | Main Keel | 38 Main Runner | 38*12 | 0.6/0.8/1.0/1.2 |
| 50 Main Runner | 50*15 | 1.0/1.2 | ||
| 60 Main Runner | 60*27 | 1.0/1.2 | ||
| Furring Channel | 50 Cross Runner | 50*19 | 0.34/0.5/0.6 | |
| 60 Cross Runner | 60*27 | 0.5 | ||
| Partition | Transverse Keel (U Track) |
50 Metal Track | 50*35 | 0.46/0.65 |
| 75 Metal Track | 75*40 | 0.46/0.57 | ||
| 100 Metal Track | 100*40 | 0.5/0.7/0.8 | ||
| 150 Metal Track | 150*40 | 0.6/0.8 | ||
| Vertical Keel (C Type) |
50 Vertical Keel | 50*50 | 0.46/0.53/0.65 | |
| 75 Vertical Keel | 75*50 | 0.5/0.6/0.8 | ||
| 100 Vertical Keel | 100*50 | 0.5/0.6/0.8 | ||
| 150 Vertical Keel | 150*50 | 0.7/0.8/1.0 | ||
